Metabolic profiling of root exudates from two ecotypes of sedum alfredii treated with pb based on gc-ms

ABSTRACT Phytoremediation is an effective method to remediate Pb-contaminated soils and root exudates play an important role in this process. Based on gas chromatography-mass spectrometry

(GC-MS) and metabolomics method, this study focuses on the comparative metabolic profiling analysis of root exudates from the Pb-accumulating and non-accumulating ecotypes of _Sedum

alfredii_ treated with 0 and 50 μmol/L Pb. The results obtained show that plant type and Pb stress can significantly change the concentrations and species of root exudates, and fifteen

compounds were identified and assumed to be potential biomarkers. Leaching experiments showed that l-alanine, l-proline and oxalic acid have a good effect to activate Pb in soil, glyceric

acid and 2-hydroxyacetic acid have a general effect to activate Pb in soil. 4-Methylphenol and 2-methoxyphenol might be able to activate Pb in soil, glycerol and diethyleneglycol might be

able to stabilize Pb in soil, but these activation effect and stabilization effect were all not obvious. SIMILAR CONTENT BEING VIEWED BY OTHERS IDENTIFICATION OF THE RHIZOSPHERIC MICROBE AND

METABOLITES THAT LED BY THE CONTINUOUS CROPPING OF RAMIE (_BOEHMERIA NIVEA_ L. GAUD) Article Open access 23 November 2020 ELUCIDATING THE SIGNIFICANT ROLES OF ROOT EXUDATES IN ORGANIC

POLLUTANT BIOTRANSFORMATION WITHIN THE RHIZOSPHERE Article Open access 29 January 2024 COMBINED METAGENOMIC AND METABOLOMIC ANALYSES REVEAL THAT _BT_ RICE PLANTING ALTERS SOIL C-N METABOLISM

Article Open access 23 January 2023 INTRODUCTION In response to soil heavy metal pollution, timely treatment and remediation is essential. Phytoremediation, as an emerging green and _in-

situ_ remediation technology, is widely used to remediate heavy metal contaminated soils. This technology uses plants to remove pollutants from the environment or to render them harmless,

including phytoextraction, phytodegradation, rhizofiltration, phytostabilization and phytovolatilization1,2,3. For Pb-contaminated soils, phytoextraction and phytostabilization are the main

remediation technologies used. Accumulator plant, species which have the ability to take up heavy metals from the soil to a level higher than the substrate soil, is a key factor for the

phytoremediation of heavy metals4. Root exudates are important to the mechanisms of how accumulator species absorb, accumulate and tolerate heavy metals. Root exudates are plant metabolites

that are released to the root surface or into the rhizosphere to enhance plant nutrient uptake or cope with environmental- stress, and include low- molecular- weight organic acids, amino

acids, sugars, amides, aliphatic acids, aromatic acids, vitamins, peptides, proteins, enzymes, plant hormones, alcohols, ketones, olefins, urea and phytoalexins5,6,7,8. The composition and

quantity of root exudates vary from plant to plant with two very important factors. One is the plant’s inherent biology, such as plant species and growth cycle; the other is the external

environment of plant growth, i.e. soil and its elemental content9. Root exudates can modify the pH and redox potential (Eh) of the rhizosphere; chelate, complex and deposit heavy metals and

alter the number and activity of rhizosphere microbes. Through these processes, root exudates can change the chemical speciation of heavy metals and increase or decrease their

bio-availability10. Low- molecular- weight organic acids (LMWOAs) have a strong ability to bind with heavy metals11,12,13,14. For example, citric acid and oxalic acid can enhance the

translocation of Cd, Cu and Pb from roots to shoots15,16. In addition, it has also been shown that dissolved organic matter (DOM), derived from the rhizosphere of _Sedum alfredii_, can

significantly reduce Zn and Cd sorption and increase metal mobility through the formation of soluble DOM-metal complexes17. However, the variations in root exudates between accumulator and

non-accumulator plant species under different stresses which based on an approximate global analysis have rarely been reviewed. Metabolic profiling is one of the most pragmatic approaches of

metabolomics research strategies; it aims at extracting, separating and analyzing a spectrum of metabolites as broad as possible from complex matrices in an effective and reproducible

way18. It reflects the different metabolic states of the organism and identifies specific biomarkers to describe and distinguish between different states of biological systems19. Our group

has used metabolic profiling analysis, based on GC-MS technology, to research the variation of root exudates from the Cd hyperaccumulator _S. alfredii_ under different Cd exposure

concentrations and times, and to identify potential biomarkers20,21. Based on GC-MS technology, the present study focused on the metabolic profiling analysis of root exudates from the

Pb-accumulating and non-accumulating ecotypes of _Sedum alfredii_ treated with 0 and 50 μmol/L Pb to find potential biomarkers associated with accumulation or toleration. And the function of

some potential biomarkers was preliminarily discussed by using leaching experiment. RESULTS PLANT GROWTH AND PB ACCUMULATION In hydroponic experiments, the accumulating ecotype (AE) showed

better growth, an erect stem and thicker dark green leaves, while the non-accumulating ecotype (NAE) showed small, thin, and light green leaves. Lead did not significantly affect the growth

and appearance of the shoot of the accumulating ecotype when treated with 50 μmol/L Pb. For the non-accumulating ecotype, Pb significantly inhibited plant growth (dry weight, DW) and the

color of leaves changed from light green to dark green as the Pb concentration in the solution increased from 0 to 50 μmol/L (Fig. 1). The amount of Pb accumulated by most plant species is

very limited22. The accumulating ecotype of _S. alfredii_, however, was shown to accumulate appreciable quantities of Pb. When treated with 50 μmol/L Pb, the Pb concentrations in the shoots

and roots of the accumulating ecotype were, respectively, 136.8 mg/kg (DW) and 893.7 mg/kg (DW). Compared to the accumulating ecotype, the non-accumulating ecotype accumulated less Pb with

Pb concentration of 73.9 mg/kg (DW) in the shoots and 2510.9 mg/kg (DW) in the roots (Table 1). The root- to- shoot transfer of Pb in plants is usually low22,23. When Pb enters the plant

root, it encounters the neutral pH, high phosphate, and high carbonate environment of the intercellular spaces. Under these conditions, Pb precipitates as phosphate or carbonate and does not

reach the xylem for translocation24,25. However, a higher transfer coefficient (shoot/root ratio of heavy metal concentration in plant) is important for the practical phytoremediation of

heavy metal-contaminated soils. It has been shown that Pb hyperaccumulators usually have a higher transfer coefficient (0.04–0.10) than non-hyperaccumulators species26. In this study, the

transfer coefficient of the accumulating ecotype treated with 50 μmol/L Pb was 0.15, while that of the non-accumulating ecotype was 0.03, thus, demonstrating that the accumulating ecotype

was more effective in transporting Pb from the roots to the shoots than the non-accumulating species (Table 1). METABOLIC PROFILING BY GC-MS Fifty-six compounds were detected and identified

in metabolic profiling by GC-MS (Fig. 2). The relative contents of these fifty-six compounds were listed in the Supplemental file (Supplemental file 1: Supplemental Table 1). PATTERN

RECOGNITION ANALYSIS OF METABOLIC PROFILING We pursued two multivariate data analysis approaches to differentiate metabolic changes based on the identified root exudates and identify

potential biomarkers; an unsupervised method based on principal component analysis (PCA) and a supervised method based on orthogonal partial least-squares discrimination analysis (OPLS-DA).

In this work, PCA was firstly performed to classify the metabolic phenotypes. In the PCA score plot (Fig. 3A), a single data point represents a sample, and points clustered together have a

more similar biochemical makeup than that of points located apart27. The score plot demonstrated a sharp separation amongst the different ecotypes under different Pb stress, suggesting that

the plant species and Pb stress can significantly influence the composition and quantity of the root exudates. However, the group of the AE treated with 50 μmol/L Pb was found to be close to

the group of the AE treated with 0 μmol/L Pb, which indicates that a low dose of Pb exerted little influence on the AE. OPLS-DA was then used to maximize the difference between the groups.

As showed in Fig. 3B, different groups have a clear separation, indicating that the variation of root exudates caused by plant species and Pb stress. IDENTIFICATION OF POTENTIAL BIOMARKERS

The use of loading and variable importance in the projection (VIP) score plots in combination can detect differentiating metabolites and potential biomarkers. The loading (Fig. 3C) and VIP

plots (Fig. 3D) generated after OPLS-DA processing were applied to interpret the metabolic pattern, and visually show the weight of mass spectral signals attributed to the clustering and

discrimination observed in the scores plots. The threshold of VIP values was set to 1.0. An analysis of variance (ANOVA, _p_ < _0.05_) was further performed to assess the statistical

validity of the multivariate analysis and select potential biomarkers. Finally, fifteen compounds were detected and assumed as potential biomarkers (Fig. 4). As can be seen from the Fig. 4,

l-alanine, l-proline, oxalic acid, 4-methylphenol and 2-methoxyphenol were only secreted when the AE was under Pb stress, but glyceric acid was only secreted when the NAE was under Pb

stress. Under Pb treatments, the secretions of 2-hydroxyacetic acid, oleic acid, glycerol, diethyleneglycol, and 1-monohexadecanoylglycerol were increased in NAE, but were reduced from AE.

Under Pb treatment, the secretions of 9-hexadecenoic acid, n-pentadecanoic acid and dodecanol increased, while the secretion of beta-sitosterol decreased for both the AE and the NAE.

FUNCTION OF POTENTIAL BIOMARKERS For further researching the function of potential biomarkers, a series of leaching experiment were performed. Because of oleic acid,

1-monohexadecanoylglycerol, 9-hexadecenoic acid, n-pentadecanoic acid, dodecanol and beta-sitosterol are poorly soluble or insoluble in water, the leaching experiments of these compounds

were not conducted. In addition, the concentration of root exudates such as organic acid, amino acid around rhizosphere is low, so a series low concentration of leaching experiment were

carried out. It can be seen from Table 2 that l-alanine and l-proline could activate Pb in soil, and the activation effect increased with the increase of the concentration of l-alanine and

l-proline. The highest activation rate was 3.218% and 2.795%, respectively. When the concentration was 2 mmol/L, the extraction of oxalic acid was lower than the control (0 mmol/L). But when

the concentration increased to 4 mmol/L, the extraction was obviously higher than the control, and the activation effect increased with the increase of the concentration of oxalic acid. The

highest activation rate was 4.618%. 4-Methylphenol and 2-methoxyphenol might be able to activate Pb in soil, but the activation effect was not obvious, the highest activation rate was

merely 0.243% and 0.256%, respectively. Glyceric acid and 2-hydroxyacetic acid also could activate Pb in soil, only the activation effect was lower, and obviously lower than the activation

effect of oxalic acid, l-alanine and l-proline. The extraction of glycerol and diethyleneglycol were all lower than the control, may be these two compounds could stabilize Pb in soil, but

these stabilization effects were not obvious. DISCUSSION The ability of plants to tolerate and accumulate heavy metals is very important for phytoremediation. As an accumulator, it first

needs to be resistant to many heavy metals. Secondly, it needs to solubilize heavy metals around the rhizosphere and lastly, the plant must absorb heavy metals in the over-ground part of

plants. In these processes, root exudates play an important role28,29. Root exudates have many different kinds, can change quickly, and are influenced by many factors, such as soil

structure, plant species, environmental- stress, and so on refs 6,30. In this study, fifty-six compounds from the two ecotypes of _S. alfredii_ were detected and identified, though there

were many chromatographic peaks which were not identified. Based only on these fifty-six compounds, obvious differences in quantity or composition of the root exudates released from the two

ecotypes of _S. alfredii_ under Pb stress were detected by PCA and OPLS-DA. In this study, fifteen compounds resulted in an obvious separation between different treatments were identified

based on the loadings plot and the VIP values of OPLS-DA and ANOVA. We speculate that these fifteen compounds might play a main role in the process of _S. alfredii_ to tolerate or accumulate

Pb. This role may be to mobilize or stabilize Pb. Leaching experiments showed that l-alanine, l-proline and oxalic acid have a good effect to activate Pb in soil. Glyceric acid and

2-hydroxyacetic acid could activate Pb in soil, but the activation effect is poorer. 4-Methylphenol and 2-methoxyphenol might be able to activate Pb in soil, glycerol and diethyleneglycol

might be able to stabilize Pb in soil, but these activation effect and stabilization effect were all not obvious. Previous researches have demonstrated that organic acids and amino acids

play an extremely important role in the process of how accumulator species tolerate and accumulate heavy metals31,32,33. Oxalic acid can potentially liberate Pb from pyromorphite in

contaminated soils34. Debela _et al_. concluded that the abundance of oxalic acid and citric acid in soil environments can be one factor contributing to the poor efficiency of P amendment

practices to effectively immobilize Pb and Zn in metal contaminated soils35. Cui _et al_. considered that 1.2 mmol/L oxalic acid significantly (P < 0.05) increased Pb uptake when seeds

(_Zinnia elegans_ Jacq.) were treated with 2.4 mmol/L Pb36. In this study, oxalic acid was selected as the potential biomarker and has a good effect to activate Pb in soil. When the pH of

the system was high, oxalic acid could form insoluble Pb-oxalate complexes on the soil surface with Pb37. So under the low concentration, the extraction of oxalic acid was lower than the

control. Organic acids could reduce the pH around the rhizosphere, and then activated the insoluble minerals in soils, improved the bioavailability of heavy metals38,39. In this study,

glyceric acid and 2-hydroxyacetic acid were selected as the potential biomarker and could activate Pb in soil. Because of glyceric acid and 2-hydroxyacetic acid are weak acid, the activation

effect of these two compounds were general. L-proline and l-histidine may increase Cd accumulation by _Solanum nigrum_40. L-cysteine has been shown to form neutral stable complexes with Pb

and decrease its sorption on palygorskite and sepiolite; whereas l-histidine formed cationic soluble His–Pb complexes which were slightly adsorbed by the surfaces of sepiolite via

electrostatic attraction and reduced the Pb sorption capacity of sepiolite41. In this study, l-alanine and l-proline were selected as the potential biomarkers and have a good effect to

activate Pb in soil. The hydroxyl or OH-phenolic groups could complexing react with heavy metal ions in soil, formed a stable complex compound and reduced the activity of heavy metal ions42.

But Mench _et al_. pointed out that organic acids, amino acids and phenolic compounds could react with heavy metal ions to form soluble compounds, and then improve the bioavailability of

heavy metals43. Glycerol and diethyleneglycol have hydroxyl group, so these two compounds might be able to stabilize Pb in soil. 4-Methylphenol and 2-methoxyphenol are phenolic compounds

which have OH-phenolic group, so the roles of these two compounds are complicated. In this study, glycerol and diethyleneglycol might be able to stabilize Pb in soil, 4-methylphenol and

2-methoxyphenol might be able to activate Pb in soil, but these activation effect and stabilization effect were all not obvious. The function of other potential biomarkers, such as

9-hexadecenoic acid, n-pentadecanoic acid, and so on, were not discussed in this study, because of these compounds are poorly soluble or insoluble in water. The way which root exudates

activate heavy metals in soil have many, such as the indirect activation of microbes44, these compounds maybe used this approach. We will research these in the further. Based on the GC-MS

and metabolomics results, this study has focused on the comparative metabolic profiling analysis of root exudates from the Pb-accumulating and non-accumulating ecotypes of _Sedum alfredii_

under Pb stress. The results obtained show that plant type and Pb stress can significantly change the levels and species of root exudates, fifteen compounds were identified and assumed as

potential biomarkers. Through leaching experiments, the functions of some potential biomarkers were discussed. L-alanine, l-proline and oxalic acid have a good effect to activate Pb in soil,

glyceric acid and 2-hydroxyacetic acid have a general effect to activate Pb in soil. 4-Methylphenol and 2-methoxyphenol might be able to activate Pb in soil, glycerol and diethyleneglycol

might be able to stabilize Pb in soil, but these activation effect and stabilization effect were all not obvious. METHODS CHEMICALS AND REAGENTS Methanol (HPLC grade) was bought from Fisher

(USA). Methoxamine hydrochloride and N-methyl-N-(trimethylsilyl) trifluoracetamide (MSTFA) were obtained from Sigma (USA). Compositions of the nutrient solution, Pb(NO3)2, NaOH, HCl, NaNO3,

l-alanine, l-proline, oxalic acid, glyceric acid, 2-hydroxyacetic acid, glycerol, diethyleneglycol, 4-methylphenol and 2-methoxyphenol (analytic grade) and pyridine (HPLC grade) were

purchased from Sinopharm Chemical Reagent Co., Ltd. (ShangHai, China). PLANT CULTURE Seedlings of _S. alfredii_ were cultivated hydroponically. Accumulating ecotype of _S. alfredii_ (AE) was

collected from an old Pb/Zn mining area in Quzhou City, Zhejiang Province, China. Non-accumulating ecotype of _S. alfredii (Sedum Sarmentoum Bunge_) (NAE) was obtained from suburb of

Shenyang in Liaoning Province of China. After having collected the plants, they were grown in non-contaminated soil in Shenyang University for several generations to minimize the internal

metal contents. Uniform and healthy shoots were selected and cultivated in a basal nutrient solution containing 3.0 mmol/L KNO3, 0.5 mmol/L NH4H2PO4, 2.0 mmol/L Ca(NO3)2, 1.0 mmol/L

MgSO4·7H2O, 4.5 μmol/L MnCl2·4H2O, 23 μmol/L H3BO3, 0.4 μmol/L ZnSO4·7H2O, 0.15 μmol/L CuSO4·5H2O, 0.05 μmol/L H2MoO4·H2O, and 22 μmol/L EDTA-Fe. The nutrient solution pH was adjusted to 6.0

using 0.1 mol/L NaOH or HCl every day. Plants were grown under greenhouse conditions with natural light and the temperature varied from 10 to 20 °C. The nutrient solution was continuously

aerated and renewed every 4 days. PB TREATMENT Intact roots of two week old seedlings of _S. alfredii_ were rinsed in deionized water, and then transferred to custom-built hydroponic vessels

(one seedling in each 300 mL vessel) containing Pb uptake solution. In addition to the nutrient solution components, the uptake solution contained 0 or 50 μmol/L Pb(NO3)2. In order to

prevent Pb precipitation, the NH4H2PO4 concentration in nutrient solution was adjusted to 5 μmol/L. Each treatment was replicated eleven times. There were 44 pots (1 plant per pot) in total.

COLLECTION OF ROOT EXUDATES AND PLANTS The procedure for the collection of root exudates has been described by Hao _et al_.45 After growing for 4 days in the nutrient solution spiked with

Pb, the plants were transplanted to sterilized pots with 50 mL deionized water to collect the root exudates for 6 h. After collection, the plant roots in each pot were washed with 100 mL of

deionized water and immersed in 20 mmol/L Na2-EDTA (disodium ethylenediaminetetraacetate) for 15 min to remove Pb adhering to the root surfaces46. Then the roots and shoots were harvested

separately. PRETREATMENT OF ROOT EXUDATES AND PLANT The root exudates from each pot were frozen in liquid nitrogen and freeze-dried for 2 days. The dried residue was resuspended in 100 mL of

deionized water and freeze-dried again, then redissolved in 10 mL of cold MeOH. The sample was blown to dryness under a gentle nitrogen flow, and reconstituted in 1 mL of _n_-hexane. Then,

samples were derivatized by 40 μL methoxyamine hydrochloride (20 mg/mL in pyridine, 2 h, 37 °C) and 70 μL N-methyl-N-(trimethylsilyl) trifluoroacetamide (MSTFA) (30 min, 37 °C), for GC-MS

analysis. Refer to some previous studies for more information on this method47,48. The fresh shoots and roots were washed with deionized water, air-dried to remove the water adhering to

them, dried at 70 °C for 72 h, and then their dry weight was determined. The dried plant samples were powdered and digested using the HNO3-HClO4 method and the Pb concentration was

determined by atomic absorption spectroscopy (AAS). GC-MS ANALYSIS OF ROOT EXUDATES One microliter of each sample was injected into the GC (Thermo Trace GC Ultra-PolarisQ, USA) in the

splitless mode. GC separation was conducted on a capillary column TR-5MS (30 m × 0.25 mm × 0.25 μm, Thermo Fisher, USA). The injector temperature was controlled at 230 °C and the split rate

of the injector was 1:50. Helium was used as a carrier gas at a constant flow rate of 1.0 mL/min. The initial column temperature was kept at 70 °C for 1 min, then, the temperature was

increased from 70 °C to 76 °C at a rate of 1 °C/min, then increased from 76 °C to 330 °C at a rate of 5 °C/min and held there for 10 min. The transfer line temperature and ion-source

temperature were controlled at 250 °C and 210 °C respectively. Ionization was achieved using a 70eV electron beam. Mass spectra were recorded from m/z 50 to 600 at a rate of 2 s in full scan

mode, and the solvent delay time was 3 min. DATA PROCESSING AND MULTIVARIATE DATA ANALYSIS The GC-MS data was processed using the automatic mass spectral deconvolution and identification

system (AMDIS, version 2.71) and the metabolomics ion-based data extraction algorithm (MET-IDEA, version 2.08). The AMDIS database was a plant metabolites database containing the Fiehn and

Golm Metabolome Database (GMD) and the qualitative standard was similarity greater than 70%. The MET-IDEA input was the output of AMDIS, and the other parameters were: (i) chromatography:

GC; average peak width, 0.1; minimum peak width, 0.3; maximum peak width, 6; peak start/stop slope, 1.5; adjusted retention time accuracy, 0.95; peak overload factor, 0.3; (ii) mass spec:

trap; mass accuracy, 0.1; mass range, 0.5; (iii) AMDIS: exclude ion list, 73, 147, 281, 341, 415; lower mass limit, 50; ions per component, 1. The peak of 9.30 min detected in all of the

samples was used for retention time calibration. Subsequently, each peak area of the identified root exudates was normalized according to each compound based on the first appeared. The

normalization method was the peak area values divided by the average of the compound which first appeared. Multivariate data analysis was achieved on the normalized GC-MS datasets with

software package SIMCA-P (version 13.0, Umetrics, Sweden). Principal component analysis (PCA) was carried out on the dataset to generate an overview of the sample distribution and observe

possible outliers. The orthogonal partial least-squares discrimination analysis (OPLS-DA) was further performed with the unit-variance scaled GC-MS data as X matrix and class information as

Y matrix to identify the metabolites that significantly contribute to intergroup differentiation. The OPLS-DA models were validated using a seven-fold cross validation method and the quality

of the model was described by the parameters R2X and Q2 values. The Variable Importance in the Projection (VIP) value (VIP > 1) was used to evaluate the variable contribution and

identify the potential biomarkers. The univariate statistical analysis was performed by SPSS 19.0 for further identification of potential biomarkers, including box figure analysis and

analysis of variance (ANOVA), and _p_-value was set as 0.05 for statistical significance. LEACHING EXPERIMENT The soil used in this study was collected from the Shenyang Zhangshi Irrigation

Area, located in the western suburbs of Shenyang. Soil sample was air dried and sieved through a 2-mm sieve. The physical-chemical characteristics of the soil sample are presented: organic

matter, 2.1%; pH, 6.4; CEC (cation-exchanged capacity), 16.8 cmol/kg; clay, 40.1%, loam, 41.3%, sandy, 18.6%. The content of Pb in the soil is 72.4 mg/kg. A batch experiment was performed

with the potential biomarker as an extractant to test the effects of potential biomarker. Three series of plastic tubes were filled with 20 mL NaNO3 solution (0.1 mol/L in deionized water)

containing various concentrations of one of the potential biomarkers. The concentration was 0, 2, 4, 8, 16 mmol/L, respectively. Each tube received 2 g of soil and was shaken for 3 h at 20 

°C, then centrifuged at 7000 rpm for 20 min. The supernatants were filtered through a Whatman NO. 42 paper, and the filtrates were analyzed for Pb by AAS. ADDITIONAL INFORMATION HOW TO CITE

THIS ARTICLE: Luo, Q. _et al_. Metabolic profiling of root exudates from two ecotypes of _Sedum alfredii_ treated with Pb based on GC-MS. _Sci. Rep._ 7, 39878; doi: 10.1038/srep39878 (2017).

PUBLISHER'S NOTE: Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations. REFERENCES * Zhou, Q. X. & Song, Y. F.

_Principles and Methods of Contaminated Soil Remediation_ 134–136 (Chinese Science Press, 2004). * Sun, R. L. & Zhou, Q. X. Heavy metal tolerance and hyperaccumulation of higher plants

and their molecular mechanisms: a review. _Acta Phytoecologica Sinica._ 29, 497–504 (2005). CAS  Google Scholar  * Liu, D. et al. Comparison of synthetic chelators and low molecular weight

organic acids in enhancing phytoextraction of heavy metals by two ecotypes of _Sedum alfredii_ Hance. _J Hazard Mater_. 153, 114–122 (2008). Article  CAS  Google Scholar  * Li, T. Q., Di, Z.

Z., Yang, X. E. & Sparks, D. L. Effects of dissolved organic matter from the rhizosphere of the hyperaccumulator _Sedum alfredii_ on sorption of zinc and cadmium by different soils. _J

Hazard Mater_. 92, 1616–1622 (2011). Article  Google Scholar  * Curl, E. A. & Truelove, B. The Rhizosphere In _Advanced Series in Agricultural Sciences_ (eds. Yaron, B. et al.) 55–92

(Springer, 1986). * Selvakumar, G., Panneerselvam, P. & Ganeshamurthy, A. N. _Bacterial mediated alleviation of abiotic stress in crops in Bacteria in Agrobiology: Stress Management_

(ed. Maheshwari, D. K. ) 205–224 (Springer, 2012). * Marschner, H. _Mineral Nutrition of Higher Plants_ (Second Edition). 547–548 (Academic Press, 1995). * Kuang, Y. W., Wen, D. Z., Zhong,

C. W. & Zhou, G. Y. Root exudates and their roles in phytoremediation. _Acta Phytoecologica Sinica_. 27, 709–717 (2003). CAS  Google Scholar  * Prasad, M. N. V. & Freitas, H. M.

Metal hyperaccumulation in plants-Biodiversity prospecting for phytoremediation technology. _Electron J. Biotechn_. 6, 286–305 (2003). Google Scholar  * Jiang, C. A. et al. Dissolution of

different zinc salts and Zn uptake by _Sedum alfredii_ and maize in mono- and co-cropping under hydroponic culture. _J Environ Sci (China)_. 25, 1890–1896 (2013). Article  CAS  Google

Scholar  * Sun, R. L., Zhou, Q. X., Sun, F. H. & Jin, C. X. Antioxidative defense and proline/phytochelatin accumulation in a newly discovered Cd-hyperaccumulator, _Solanum nigrum_ L.

_Environmental and Experimental Botany_. 60, 468–476 (2007). Article  CAS  Google Scholar  * Sun, R. L., Zhou, Q. X. & Jin, C. X. Cadmium accumulation in relation to organic acids in

leaves of _Solanum nigrum_ L. as a newly-found cadmium hyperaccumulator. _Plant and Soil_ 285, 125–134 (2006). Article  CAS  Google Scholar  * Chiang, P. N., Chiu, C. Y., Wang, M. K. &

Chen, B. T. Low-molecular-weight organic acids exuded by Millet (_Setaria italica_(L.) Beauv.) roots and their effect on the remediation of cadmium-contaminated soil. _Soil Science._ 176,

33–38 (2011). Article  CAS  ADS  Google Scholar  * Kim, S., Lim, H. & Lee, I. Enhanced heavy metal phytoextraction by _Echinochloa crus-galli_ using root exudates. _J Biosci Bioeng_.

109, 47–50 (2010). Article  CAS  Google Scholar  * Zhou, Q. X., Wei, S. H. & Zhang, Q. R. _Ecological Remediation_ 127–133 (China Environmental Science Press, 2006). * Fan, T. W. M. et

al. Comprehensive chemical profiling of gramineous plant root exudates using high-resolution NMR and MS. _Phytochem._ 57, 209–221 (2001). Article  CAS  Google Scholar  * Jiang, C. A. et al.

Dissolution of different zinc salts and Zn uptake by Sedum alfredii and maize in mono- and co-cropping under hydroponic culture. _Journal of Environmental Sciences (China)_. 25, 1890–1896

(2013). Article  CAS  Google Scholar  * Shu, X. L., Frank, T., Shu, Q. Y. & Engel, K. H. Metabolite Profiling of Germinating Rice Seeds. _J. Agric. Food Chem._ 56, 11612–11620 (2008).

Article  CAS  Google Scholar  * Wang, M. et al. Metabolic profiling analysis of fatty acids from hyperlipidemic rats treated with Gynostemma pentaphyllum and atorvastatin based on GC/MS.

_Anal. Methods_ 6, 8660–8667 (2014). Article  CAS  Google Scholar  * Luo, Q., Sun, L. N., Hu, X. M. & Zhou, R. R. The Variation of Root Exudates from the Hyperaccumulator _Sedum

alfredii_ under Cadmium Stress: Metabonomics Analysis. _PLoS One_ 9, e115581, 10.1371/journal.pone.0115581 (2014). Article  ADS  Google Scholar  * Luo, Q., Sun, L. N., Wang, H. & Hu, X.

M. Metabolic profiling analysis of root exudates from the Cd hyperaccumulator _Sedum alfredii_ under different Cd exposure concentrations and times. _Anal. Methods_ . 7, 3793–3800 (2015). *

Kochian, L. V. _Mechanisms of micronutrient uptake and translocation in plants_ In _Micronutrients in Agriculture_ (eds. Mortved, J. J., Cox, F. R., Shuman, L. M. & Welch, R. M. )

229–296 (Madison, 1991). * Begonia, G. B., Davis, M. F. T. & Gray, B. C. N. Growth responses of Indian Mustard (_Brassica juncea_ (L.) Czern. et Cross) and its phytoextraction of lead

from a contaminated soil. _Bull Environ Contam Toxicol_. 61, 38–43 (1998). Article  CAS  Google Scholar  * Malone, C., Koeppe, D. E. & Miller, R. J. Localization of lead accumulated in

corn plants. _Plant Physiol._ 53, 388–394 (1974). Article  CAS  Google Scholar  * Qureshi, J. A., Hardwick, K. & Collin, H. A. Intracellular localization of lead in a lead tolerant and

sensitive clone of Anthoxanthum odoratum. _J Plant Physiol_. 122, 357–364 (1986). Article  CAS  Google Scholar  * Kumar, N., Dushenkov, V., Motto, H. & Raskin, I. Phytoextraction: the

use of plants to remove heavy metals from soils. _Environ Sci Techn_. 29, 1232–1238 (1995). Article  CAS  ADS  Google Scholar  * Robertson, D. G. Metabonomics in toxicology: A review.

_Toxicol. Sci._ 85, 809–822 (2005). Article  CAS  Google Scholar  * Quartacci, M. F. et al. Naturally-assisted metal phytoextraction by _Brassica carinata_: role of root exudates.

_Environmental Pollution_ 157, 2697–2703 (2009). Article  CAS  Google Scholar  * Wei, S. H. & Zhou, Q. X. Phytoremdiation of cadmium-contaminated soils by Rorippa globosa using two-phase

planting. _Environmental Science & Pollution Research_. 13, 151–155 (2006). Article  CAS  Google Scholar  * Carvalhais, L. C. et al. Root exudation of sugars, amino acids, and organic

acids by maize as affected by nitrogen, phosphorus, potassium, and iron deficiency. _J. Plant Nutr. & Soil Sci._ 174, 3–11 (2011). Article  CAS  Google Scholar  * Boominathan, R. &

Doran, P. M. Organic acid complexation, heavy metal distribution and the effect of ATPase inhibition in hairy roots of hyperaccumulator plant species. _Journal of Biotechnology_. 101,

131–146 (2003). Article  CAS  Google Scholar  * Sun, R. L., Zhou, Q. X. & Jin, C. X. Cadmium accumulation in relation to organic acids in leaves of _Solanum nigrum_ L. as a newly found

cadmium hyperaccumulator. _Plant & soil_ 285, 125–134 (2006). Article  CAS  Google Scholar  * Yang, X. E. et al. Dynamics of zinc uptake and accumulation in the hyperaccumulating and

non-hyperaccumulating ecotypes of _Sedum alfredii_ Hance. _Plant & Soil_ . 284, 109–119 (2006). * Debela, F., Arocena, J. M., Thring, R. W. & Whitcombe, T. Organic acid-induced

release of lead from pyromorphite and its relevance to reclamation of Pb-contaminated soils. _Chemosphere._ 80, 450–456 (2010). Article  CAS  ADS  Google Scholar  * Debela, F., Arocena, J.

M., Thring, R. W. & Whitcombe, T. Organic acids inhibit the formation of pyromorphite and Zn-phosphate in phosphorous amended Pb- and Zn-contaminated soil. _Journal of Environmental

Management_. 116, 156–162 (2013). Article  CAS  Google Scholar  * Cui, S. et al. Effects of exogenous chelators on phytoavailability and toxicity of Pb in _Zinnia elegans_ Jacq. _Journal of

Hazardous Materials_. 146, 341–346 (2007). Article  CAS  Google Scholar  * Wasay, S. A., Barrington, S. F. & Tokunaga, S. Remediation of soils polluted by heavy metals using salts of

organic acids and chelating agents. _Environmental Technology_ 19, 369–379 (1998). Article  CAS  Google Scholar  * Wang, J. L. & Lin, Z. Y. Behavior of heavy metals in rhizosphere I.

Rhizosphere effect on Cu adsorption on soils. _Acta Scientiae Circumstantiae (Chinese)_ 11, 178–185 (1991). CAS  Google Scholar  * Lu, W. L., Cao, Y. P. & Zhang, F. S. Role of

root-exuded organic acids in mobilization of soil phosphorus and micronutrients. _Chinese Journal of Applied Ecology_. 10, 379–382 (1999). Google Scholar  * Xu, J. et al. Comparative

physiological responses of _Solanum nigrum_ and _Solanum torvum_ to cadmium stress. _New Phytologist._ 196, 125–138 (2012). Article  CAS  Google Scholar  * Shirvani, M., Sherkat, Z.,

Khalili, B. & Bakhtiary, S. Sorption of Pb(II) on palygorskite and sepiolite in the presence of amino acids: Equilibria and kinetics. _Geoderma._ 249, 21–27 (2015). Article  ADS  Google

Scholar  * Inskeep, W. P. & Womfort, S. D. Thermodynamic prediction for the effect of root exudates on mental speciation in the rhizosphere. _J. plant_. 9, 567–586 (1986). CAS  Google

Scholar  * Mench, M., Morel, J. L., Guckert, A. & Guillet, B. Metal binding with root exudates of low molecular weight. _J.Soil Sci_. 39, 521–527 (1988). Article  CAS  Google Scholar  *

Brace, E. P. Phytoremediation of contaminated soil and ground water at hazardous waste sites. _EPA ORD Ground Water Issue_ (EPA/540/S-01/500, 2001). * Hao, W. Y., Ren, L. X., Ran, W. &

Shen, Q. R. Allelopathic effects of root exudates from watermelon and rice plants on _Fusarium oxysporum_ f.sp. _niveum_ . _Plant & soil_. 336, 485–497 (2010). Article  CAS  Google

Scholar  * Yang, X. E., Baligar, V. C., Martens, D. C. & Clark, R. B. Cadmium effects on influx and transport of mineral nutrients in plant species. _J. Plant Nutr._ 19, 643–656 (1996).

Article  CAS  Google Scholar  * Katsumasa, S. et al. Gas chromatography–mass spectrometry associated global analysis of rice root exudates under aseptical conditions. _Soil Science and Plant

Nutrition_. 55, 505–513 (2009). Article  Google Scholar  * Lisec, J. et al. Gas chromatography mass spectrometry–based metabolite profiling in plants. _Nature Protocols_, 1, 387–396 (2006).

Article  CAS  Google Scholar  Download references ACKNOWLEDGEMENTS We are grateful to the financial support from the National Program on Key Basic Research Project of China (973 Program)

(NO. 2014CB441100), National Natural Science Foundation of China (NO. 41401352) and the project of Shenyang Science and Technology plan (NO. F14-133-9-00). The funder had no role in study

design, data collection and analysis, decision to publish, or preparation of the manuscript. AUTHOR INFORMATION AUTHORS AND AFFILIATIONS * Key Laboratory of Regional Environment and

Eco-Remediation of Ministry of Educatione, College of Environment, Shenyang University, Shenyang, 110044, China Qing Luo, Shiyu Wang, Li-na Sun & Hui Wang Authors * Qing Luo View author

publications You can also search for this author inPubMed Google Scholar * Shiyu Wang View author publications You can also search for this author inPubMed Google Scholar * Li-na Sun View

author publications You can also search for this author inPubMed Google Scholar * Hui Wang View author publications You can also search for this author inPubMed Google Scholar CONTRIBUTIONS

Q.L. and L.S. conceived and designed the experiments. Q.L., S.W. and H.W. performed the experiments. Q.L. analyzed the data and wrote the manuscript. L.S. and H.W. contributed

regents/materials/analysis tools. CORRESPONDING AUTHOR Correspondence to Li-na Sun. ETHICS DECLARATIONS COMPETING INTERESTS The authors declare no competing financial interests.

SUPPLEMENTARY INFORMATION SUPPLEMENTARY TABLE 1 (PDF 21 KB) RIGHTS AND PERMISSIONS This work is licensed under a Creative Commons Attribution 4.0 International License. The images or other

third party material in this article are included in the article’s Creative Commons license, unless indicated otherwise in the credit line; if the material is not included under the Creative

Commons license, users will need to obtain permission from the license holder to reproduce the material. To view a copy of this license, visit http://creativecommons.org/licenses/by/4.0/

Reprints and permissions ABOUT THIS ARTICLE CITE THIS ARTICLE Luo, Q., Wang, S., Sun, Ln. _et al._ Metabolic profiling of root exudates from two ecotypes of _Sedum alfredii_ treated with Pb

based on GC-MS. _Sci Rep_ 7, 39878 (2017). https://doi.org/10.1038/srep39878 Download citation * Received: 27 July 2016 * Accepted: 28 November 2016 * Published: 04 January 2017 * DOI:

https://doi.org/10.1038/srep39878 SHARE THIS ARTICLE Anyone you share the following link with will be able to read this content: Get shareable link Sorry, a shareable link is not currently

available for this article. Copy to clipboard Provided by the Springer Nature SharedIt content-sharing initiative
