Mass spectrometry: playing catch up

Mass spectrometry is more than ever at the forefront of functional proteomics research. The technology has come a long way, but what does the future hold? Nathan Blow gets perspectives,

predictions and wishes from key developers. You have full access to this article via your institution. Download PDF “What we have seen in the past decade was mostly improvements on existing

technologies,” says Franz Hillenkamp of the University of Munster. John Yates of the Scripps Research Institute views mass spectrometry as basically evolving at a steady rate, with

occasional leaps in the technology that spur researchers and developers forward. “Those usually occur when there are new ionization techniques developed,” says Yates. Is your wish on the

list? Let us know either way by posting to _Methagora_, the _Nature Methods_ comment forum. One way to make your wishes come true is to let the developers know what you really want. (Card

design by Eszter Rabin.) One thing is clear, however: consistent improvements in mass spectrometry instruments over the past decade have been enabling research that was unheard of before,

driving the establishment of mass spectrometry as a critical technology for biologists. RISE OF THE HYBRIDS When asked what the biggest innovation in mass spectrometry instrumentation has

been in the last five years, Yates has a quick reply: “I would say that it has been the rise of the 'hybrids'.” And this opinion is echoed by many mass spectrometry specialists.

Matthias Mann thinks software improvements are crucial for the advancement of mass spectrometry. Hybrid mass spectrometry instruments integrate systems with different operating principles

into a single machine, combining the benefits of both. According to Yates, the quadrupole time-of-flight (qTOF) systems set the stage for researchers to demand increased resolution and mass

accuracy from these hybrid instruments. But it was development of another hybrid instrument that pushed the mass spectrometry field in terms of accuracy. “When the linear ion trap–[fourier

transform mass spectrometer (FTMS)] systems came into being, that really filled a substantial unmet need in the field,” says Yates. Fourier transform ion-cyclotron resonance mass

spectrometers (FT-ICR MS), or just FTMS, such as the apex-ultra platform from Bruker Daltonics and the Varian 900-MS Series, are capable of very high resolution and very high accuracy, which

was not previously attainable. One drawback to FTMS systems, says Yates, is that they tend not to be user-friendly, especially for the non–mass spectro-metrist. One of the most recent and

widely adopted of the hybrids arrived in 2006 when Thermo Electron introduced their hybrid LTQ Orbitrap system. “From a technical performance standpoint, this is an instrument that provides

the high-resolution accurate mass capabilities that previously could only be achieved with superconducting magnet systems,” says Lester Taylor, Thermo Fisher Scientific's director of

Product Marketing in Life Sciences Mass Spectrometry. The orbitrap mass spectrometer was first described in 2005 by Alexander Makarov and colleagues1. After ionization, ions are injected

into the orbitrap where they circle around a central inner electrode ring flanked by an outer barrel-shaped electrode. Ion masses are measured from the frequencies within the image current

generated by the orbiting ions. Matthias Mann of the Max Planck Institute of Biochemistry in Martinsried also pointed his finger directly at the LTQ Orbitrap as the hybrid instrument that he

thinks has changed the face of the mass spectrometry. “That instrument has been a quantum jump in my opinion,” says Mann. Yates agrees that the orbitrap technology is moving the mass

spectrometry field forward. “The LTQ Orbitrap is a much more user-friendly instrument in terms of maintenance and care,” says Yates, when comparing it to the highly accurate FTMS systems.

Although Yates feels the LTQ Orbitrap does not provide the same level of performance as FTMS systems, he is very happy with its combination of pretty good performance and ease of use.

'PUNCTUATED' IONIZATION Yates noted that most technological leaps during the evolution of mass spectrometry are the result of developments in ionization methods for ionizing

delicate, nonvolatile biological molecules. Today the most widely used ionization techniques for biological samples are matrix-assisted laser desorption/ionization (MALDI) and electrospray

ionization (ESI). MALDI is a soft ionization technique, developed in the mid-1980s simultaneously by Franz Hillenkamp, Michael Karas and colleagues at the University of Munster, and Koichi

Tanaka at the Shimadzu Corporation2,3. In this technique a laser beam, usually nitrogen, is focused onto a sample that is protected by a matrix (which is deposited onto a special plate). As

the matrix heats up, the sample is ionized and transferred to the gas phase. In ESI, a technique developed by John Fenn and colleagues4, the substance to be studied is dissolved in a

solvent, which is then highly charged and forced through a small capillary tube to form a fine mist of charged droplets. The solvent evaporates, leaving behind multiply charged gas-phase

ions. “MALDI and ESI came along and presented two different workflows,” says Yates. But he notes that it was ESI that filled a need in the community, providing the ability to perform online

liquid chromatography with mass spectrometry, which allowed researchers to analyze more complex samples. Carol Robinson's laboratory at the University of Cambridge is using mass

spectrometry approaches to study native proteins complexes. One of her great wishes for the future of mass spectrometry is enhanced sensitivity. “Sensitivity is still a major obstacle,

particularly for protein complexes, even though mass spectrometry is a highly sensitive technique. ESI has a lot of scope for improvement here.” The last ten years have seen the

incorporation of these ionization techniques into mass spectrometry instrumentation. “In mass spec instrumentation, one of the biggest recent advances has been the adaptation of MALDI ion

sources to many different mass analyzers,” says Hillenkamp. He also cites the incorporation of MALDI into hybrid instruments such as FT-ICR combined with linear ion traps, orbitrap systems

and even triple quadrupole systems. Detlev Suckau, head of MALDI Applications Development and Proteomics at Bruker Daltonics, thinks that for MALDI, the development of TOF/TOF

instrumentation was essential. “Without the TOF/TOF, I am afraid that the MALDI-TOF as such would have had no future in the proteomics field,” says Suckau. He also notes that this

development has enabled MALDI to be used as a tandem mass spectrometry (MS/MS) discovery tool on par with ESI. And the multiple-step mass selection of MS/MS has opened new areas for mass

spectrometry research, such as imaging of proteins and peptides. Bruker Daltonics developed its MALDI-based ultraflexIII TOF/TOF instrument for tissue biomarker discovery. The system relies

on the smartbeam laser developed at Bruker Daltonics, which can be used with most MALDI matrixes and sample preparation methods. “I would not say that this is a new method, but the

development of the smartbeam laser for MADLI-TOF/TOF shows exceptionally well that sometimes there are apparently minor technical innovations that provide access to new applications,” says

Suckau. Although both MALDI and ESI are the ionization techniques commonly used for analyzing complex biological samples, several new ionization techniques have come onto the scene in the

past couple years for use with smaller molecular compounds. One of these is direct analysis in real time (DART) ionization developed by scientists at Jeol. DART ionization places samples in

front of either helium or hydrogen gas streams containing electronically or vibrationally active neutral molecules. Other new ionization methods include desorption electrospray ionization

(DESI) and surface-assisted laser desorption/ionization (SALDI). Ionization of smaller molecules by these new techniques is very relevant now according to some scientists. Hillenkamp says

that after much work on analysis of macromolecules, he now sees the analysis of smaller, pharmaceutically relevant molecules coming back again. But it is not clear what ionization methods

will be mostly used for these molecules. “Whether any of the new ionization techniques will replace MALDI in this field remains to be seen.” THE USER MANUAL PROBLEM “One of the most pressing

issues regarding the application of mass spectrometry to the field of biology is training,” says Tim Riley, vice president and managing director of Pharmaceutical Business Operations at

Waters Corporation. Riley is far from being in the minority on this issue—most developers see training and greater understanding of mass spectrometry principles as necessities for scientists

wanting to use mass spectrometry in their research. The LTQ-Orbitrap is an example of the trend for hybrid mass spectrometers. (Courtesy of Thermo Electron.) “This is a very complex

technology, and researchers really have to be taught,” says Mann. But as more and more biologists seek out mass spectrometry solutions for their research, he predicts they will face

problems. “This whole generation has been educated with a focus on genetics, and in some cases they cannot even perform proper immunoprecipitations or fractionations,” says Mann, “while the

leading [mass spectrometry laboratories] have groups of 10–20 people that cover these areas. When biologists want to get into mass spec they get a grant for the instrument, hire one person

and buy the software—and this makes it very difficult for them to do the kind of experiments they have read about in papers.” Riley thinks that in some cases biologists might have bigger

hopes for mass spectrometry than the technology is able to deliver right now. “Many researchers have overestimated the capability of the various types of mass spectrometers that they have

employed, while underestimating the complexity of the biological samples that they need to analyze,” says Riley. He suggests that there has been a tendency to treat the mass spectrometer as

a black box that always produces accurate and reliable answers, when in fact the complexity and dynamic range of many of the biological samples have proved too challenging for many mass

spectrometry protocols. To curb some of these training issues, Waters Corporation has worked to educate users on the performance of mass spectrometry instruments. “We provide training

modules, quality control standards and test protocols to guide users through routine instrument performance checks to assure that high-quality, meaningful data [are] being produced,” adds

Riley. Even guides to mass spectrometry methods and applications directed toward biologists, such as the Focus published in _Nature Methods_ two months ago, have been appearing with greater

frequency in research journals. THE INFORMATICS CHALLENGE Although training is on the mind of many experts, Mann and Riley feel very strongly that there is now a problem for both specialists

and nonspecialists alike—software. From setting up the mass spectrometer for analysis to the management of the data, most developers will generally agree that improvements in each step

would make a tremendous difference to users. Carol Robinson's group analyzes protein complexes using mass spectrometry approaches. “The software that vendors make to control instruments

has not kept pace with the advances in the instrumentation,” comments Mann, who is sure that when the software is made more robust, flexible and intelligent, the same instruments will be

able to do much more. As an example of this he points to the headroom he sees available on orbitrap instruments: “They are very sensitive but limited in the total number of ions that can be

analyzed.” To get high resolution on the orbitrap you need to wait for a full second for the computer analysis, but in fact it takes the instrument only a few milliseconds to perform the

operation. So in principle the instrument has a headroom of ten- to a hundred-fold in sensitivity and dynamic range. “If that could be harnessed, it would make a huge difference [to have] a

dynamic range that was higher by a factor of, say 10,” says Mann. Robinson also sees a need to optimize control of the presently available instruments. “We throw away 99% of the ion current

we generate in a typical electrospray ionization experiment,” says Robinson, “so a better and more efficient way of doing these experiments would have a great impact.” Although improving the

software that controls the mass spectrometer would help both the advanced user and the beginner alike, “the most pressing issue right now in the proteomics field is data management,” says

Suckau. Even simple mass spectrometry experiments can produce incredible volumes of data. Lester Taylor notes that a complex liquid chromatography–mass spectrometry run can generate data

files that are over 1 Gb in size—composed of many thousands of spectra, each containing many hundreds if not thousands of peaks. “It is just not feasible to manually interrogate that volume

of data and get meaningful answers without automated data processing methods.” Taylor says that this is an area where Thermo Fisher Scientific is keenly aware of the need and is working on

software solutions for these large datasets and workflows. Neil Kelleher of the University of Illinois feels that a good way to address the software issues might be through a collaborative

effort between all developers. “I would love to see an NIH-catalyzed collaborative where companies and principal investigators get together and work on these software issues,” says Kelleher.

He thinks without this form of collaborative interaction, advancement of this software might take longer than necessary. Mass spectrometry has reached a unique point where small changes in

either the software or hardware could open new doors for proteomics analysis by unleashing the full power of these instruments. And for the biologist moving toward mass spectrometry, take

heart—with instrumentation all set, the goal of developers now is to make it all easier, faster and more reliable. See Table 1. Please visit _methagora_ to view and post comments on this

article. REFERENCES * Hu, Q. et al. _J. Mass Spectrom._ 40, 430–443 (2005). Article  CAS  Google Scholar  * Karas, M., Bachmann, D. & Hillenkamp, F. _Anal. Chem._ 57, 2935–2939 (1985).
