Upregulation of mapk pathway is associated with survival in castrate-resistant prostate cancer

ABSTRACT BACKGROUND: Recent evidence has implicated the MAP kinase (MAPK) pathway with the development of castrate-resistant prostate cancer (CRPC). We have previously reported gene

amplification of critical members of this pathway with the development of castrate-resistant disease. In addition, we have shown that rising Raf-1 expression, with the development of CRPC,

influences time to biochemical relapse. We therefore sought to further analyse the role of both Raf-1 and its downstream target MAPK in the molecular pathogenesis of CRPC. METHODS: Protein

expression of Raf-1 and MAPK, including their activation status, was analysed using immunohistochemistry in a database of 65 paired tumour specimens obtained before and after the development

of CRPC and correlated with other members of the pathway. RESULTS: Patients whose nuclear expression of MAPK rose with the development of CRPC had a significantly shorter median time to

death following biochemical relapse (1.40 _vs_ 3.00 years, _P_=0.0255) as well as reduced disease-specific survival when compared with those whose expression fell or remained unchanged (1.16

_vs_ 2.62 years, _P_=0.0005). Significant correlations were observed between protein expression of Raf-1 and MAPK with the type 1 receptor tyrosine kinases, Her2 and epidermal growth factor

receptor, as well as the transcription factor AP-1 in CRPC tumours. CONCLUSION: We conclude that the Her2/Raf-1/MAPK/AP-1 axis may promote the development of CRPC, leading to early relapse,

and reduced disease-specific survival. In addition, members of the pathway may act as novel therapeutic and/or diagnostic targets for prostate cancer. SIMILAR CONTENT BEING VIEWED BY OTHERS

PROSTATE CANCER Article 04 February 2021 RUVBL1 PROMOTES ENZALUTAMIDE RESISTANCE OF PROSTATE TUMORS THROUGH THE PLXNA1-CRAF-MAPK PATHWAY Article 04 May 2022 LANDSCAPE OF PROSTATE-SPECIFIC

MEMBRANE ANTIGEN HETEROGENEITY AND REGULATION IN AR-POSITIVE AND AR-NEGATIVE METASTATIC PROSTATE CANCER Article 10 April 2023 MAIN Prostate cancer is one of the highest diagnosed forms of

cancer in the western world (CancerResearchUK, 2010) and is the second most common cause of male cancer-related deaths (Debes and Tindall, 2004). If diagnosed early, the disease tends to be

localised and organ specific, in these cases radical surgery and/or radiotherapy can be highly successful. However, many patients present with an advanced form, in these cases the primary

form of treatment in the UK is based on androgen-ablation therapy, which was first established 50–60 years ago (Linja et al, 2001). This form of treatment prevents the activation of

androgen-regulated genes by reducing the level of stimulation for the androgen receptor (AR), established by Huggins and Hodges (2002) this form of treatment has remained virtually unchanged

for 60 years. This has been shown to effectively reduce tumour growth in 70–80% of men, and these are also known as hormone-naïve prostate cancer (HNPC). However, it is commonly accepted

that all patients will eventually relapse with CRPC, for which there are very limited treatment options. The development of CRPC ultimately leads to disease progression, which is the main

contributing factor for the morbidity and mortality associated with prostate cancer (Dorkin and Neal, 1997; Sciarra et al, 1999). Chemical control of androgens is effective in localised

disease; however, for high-grade, metastatic disease, the best treatment option is surgical castration (Wirth et al, 2004). Early detection of prostate cancer is hindered by an inability to

distinguish between histological presence of cancerous changes that may never progress to potentially fatal metastatic disease (Culig et al, 2002). This indicates a great need to understand

the underlying mechanisms of prostate cancer to discover new forms of detection and treatment. To address these issues, greater understanding of the mechanisms involved and development of

new treatments is urgently required, as the incidence of prostate cancer is expected to increase by 20% in the next 10–25 years (Beemsterboer et al, 1999). Currently, levels of

prostate-specific antigen (PSA) are used to determine the presence of CRPC or of progression from HNPC to CRPC (Stamey et al, 1987; Gao et al, 1997). The Raf family of serine/threonine

kinases and the MAP kinase (MAPK) pathway are heavily implicated in prostate cancer as activation of the Raf/MAPK pathway increases prostate cancer cell growth both AR-dependent and

-independent under _in vitro_ conditions (Yeh et al, 1999; Bakin et al, 2003). Members of the Raf family are activated by the Ras family of GTPases (Weinstein-Oppenheimer et al, 2000), and

translocate to the cell membrane upon activation whereupon it activates MEK (MAPKK), initiating a MAPK cascade (Weinstein-Oppenheimer et al, 2000). Mitogen-activated protein kinase has been

shown to induce Raf-1 activation, resulting in a positive feedback loop (Alessandrini et al, 1997; Weinstein-Oppenheimer et al, 2000). Mitogen-activated protein kinase has also been shown to

increase the transcription of androgen-dependent genes, independently of androgens by phosphorylation of AR or its cofactors (Abreu-Martin et al, 1999; Ueda et al, 2002; Bakin et al, 2003;

Franco et al, 2003). Mutations and gene expression deregulation of both Ras and Raf are associated with tumour growth and progression (Khleif et al, 1999; Weinstein-Oppenheimer et al, 2000).

In addition, Raf and MEK have both been shown to be overexpressed in non-metastatic and metastatic prostate cancer cells (Weinstein-Oppenheimer et al, 2000; Fu et al, 2003).

Mitogen-activated protein kinase activity has been shown to be elevated in CRPC (Abreu-Martin et al, 1999; Gioeli et al, 1999), in which activated MAPK is believed to be able to stimulate

prostate cancer cell growth independently of AR by activating various transcription factors including AP-1 (a homo- or heterodimer of phosphorylated c-jun and c-fos) and c-myc

(Weinstein-Oppenheimer et al, 2000). In fact, increased AP-1 expression has been linked to castrate resistance and decreased patient survival (Edwards et al, 2004). In addition, it has been

shown that Raf-1 expression increases with the development of CRPC and there is a significantly shorter time to relapse (Mukherjee et al, 2005). Although the Ras/Raf/MAPK pathway has been

implicated in the development of CRPC through cell-line and xenograft models (Abreu-Martin et al, 1999; Bakin et al, 2003), its precise role in the development of clinical CRPC is still

poorly understood. The further elucidation of its role would clearly have therapeutic implications, as _in vitro_ studies suggest inhibition of the pathway in conjunction with hormone

therapy or chemotherapy may provide a novel method of treatment in CRPC (Bakin et al, 2003; Zelivianski et al, 2003). Here we evaluate and discuss the expression levels of Raf-1 and MAPK

(critical members of the MAPK cascade) and their activation status in matched HNPC and CRPC tumours and correlate expression levels with type 1 tyrosine kinase receptors, as well as their

downstream targets, AR and AP-1, in the same cohort of patients. PATIENTS AND METHODS PATIENTS A total of 65 subjects who were recruited and met the specific inclusion criteria of having

developed CRPC, this was determined by: firstly an initial response to androgen deprivation therapy, defined as a fall in PSA levels of at least 50% following orchidectomy or LHRH agonists

and anti-androgen treatment. Secondly, all subjects showed a subsequent relapse (defined as a sustained rise in PSA levels despite maximal treatment). These subjects were identified

retrospectively and samples were retrieved from archived stored specimens. Formalin-fixed tumour specimens from initial diagnosis (before any therapy) and post-CRPC development were obtained

for this study, providing hormone-naïve and castrate-resistant samples for each individual, respectively. A total of 65 prostate cancer patients were included in this study (130 tumours in

total) (diagnosed between 1984 and 2000). All tumours had patient identification removed, and the clinical information database was anonymised. Ethical approval was obtained from the

Multicentre Research Ethics Committee for Scotland (MREC/01/0/36) and Local Research and Ethical Committees. Patients were only selected for analysis if they initially responded to hormone

treatment (in the form of subcapsular bilateral orchidectomy or maximum androgen blockade), but subsequently relapsed (two consecutive rises in PSA greater than 10%) and had a pre- and

post-castrate-resistant tissue sample available for analysis. Hormone-naïve tissue was obtained from 18 patients by TRUS-guided biopsy and the remaining by TURP, and castrate-resistant

tumours were all obtained by TURP. Information on AR, PSA (Edwards et al, 2003a), HER2, epidermal growth factor receptor (EGFR) 6 (Edwards et al, 2006) and AP-1 (Edwards et al, 2004)

expression levels and immunohistochemistry in each of these samples had been identified previously. IMMUNOHISTOCHEMISTRY Five micrometer paraffin-embedded tissue sections were used for

immunohistochemistry staining. Briefly, sections were de-paraffinised with xylene and rehydrated. Sections were then incubated in epitope retrieval solution (DakoCytomation, Glostrup,

Denmark) for 20 min at 96°C, and cooled down to room temperature. After antigen retrieval, sections were blocked with horse serum (1.5% horse serum/TBS) for 30 min, followed by overnight

incubation at 4°C with appropriate primary antibodies. Overall Raf-1 expression was assayed with mouse monoclonal antibodies (1 : 20 dilution; Santa Cruz Biotechnology Inc., Santa Cruz, CA,

USA), whereas the level of inactivated Raf-1 was analysed using rabbit polyclonal antibodies (1 : 25 dilution; Cell Signaling Technology, Irvine, CA, USA). Phosphorylated Raf-1 (pRaf-1)

(Ser338) was detected with a rat monoclonal antibody diluted 1 : 250 (Upstate Biotechnology, Lake Placid, NY, USA). Total p42/p44 (MAPK) as well as activated p42/p44 (phosphorylated at

Thr202/204) was assessed using rabbit polyclonal antibodies (1 : 25 and 1 : 50 dilutions, respectively; Cell Signaling Technology). After primary antibody incubation, tissue sections were

washed with TBS and incubated with biotinylated species-specific secondary antibodies (DakoCytomation). After subsequent washes with TBS, streptavidin/HRP complexes and DAB chromogene were

used to visualise staining. Tissue sections were then counterstained with haematoxylin. HISTOSCORING All immunostained tumour sections were quantified blindly and independently by two

observers, using a weighted histoscore method at high magnification ( × 400). Specific staining in each tissue section was allocated 0 (no staining), 1 (weak intensity of staining), 2

(moderate intensity) or 3 (strong intensity). The final score (maximum 300) is calculated from the sum of: STATISTICAL ANALYSIS Statistical analysis was performed using the SPSS statistical

package (version 9.0). Protein expression data was not normally distributed and is shown as median and inter-quartile ranges. Wilcoxon signed rank tests were used to compare expression

between HNPC and CRPC tumours. Correlations (nonlinear) between proteins were calculated using the Spearman rank test. Time to relapse and survival analysis was conducted using the

Kaplan–Meier method and curves were compared with the log-rank test. Strong correlations are defined as having a _P_<0.01 and _r_2⩾0.25; moderate correlations are defined as having a

_P_<0.05 and _r_2<0.25, but ⩾0.1; and weak correlations are defined with a _P_<0.05 and _r_2<0.1. RESULTS PATIENT COHORT CHARACTERISTICS The clinical data collected and recorded

for each patient included age (median: 70 years; inter-quartile range: 66–74 years), PSA level at diagnosis (median: 31 ng ml−1; inter-quartile range: 7.8–109 ng ml−1), PSA level at relapse

(median: 10 ng ml−1; inter-quartile range: 4–11 ng ml−1) and Gleason grade at diagnosis (median: 8, inter-quartile range: 7–9). All patients underwent biochemical relapse (median time to

relapse: 2.54 years; inter-quartile range: 1.51–4.62 years). All patients included in this study were deceased (median time to death after relapse: 1.37 years; inter-quartile range:

0.82–2.69). This resulted in an overall median survival time of 4.5 years (inter-quartile range: 3.00–7.01). Patients were diagnosed with locally advanced (46 patients) or metastatic (19

patients) prostate cancer, and at the time of relapse the number of patients presenting with metastatic disease had risen (40 patients). At diagnosis, patients either underwent surgery (27

orchidectomy) or androgen deprivation therapy (59 GnRH analogue and/or anti-androgen deprivation therapy). Most patients were deceased during the course of follow-up (46 patients), although

some survived beyond follow-up (19 patients). The presence of metastatic disease at diagnosis was associated with reduced time to biochemical relapse (_P_=0.037) and a trend in overall

patient survival (_P_=0.06). High Gleason scores were associated with more rapid biochemical relapse (_P_=0.002), time to death after biochemical relapse (_P_=0.02) and disease-specific

survival (_P_=0.001), confirming the association of these clinical parameters with the progression of prostate cancer. EXPRESSION AND LOCALISATION OF RAF-1 AND MAPK Raf-1 was observed in the

cytoplasm and peri-membrane areas (Figure 1A), and the inactive form of Raf-1 was found only in the peri-membrane region (Figure 1B); however, the activated form of Raf-1 was observed in

the cytoplasm, nucleus and the cell membrane (Figure 1C). Mitogen-activated protein kinase and phosphorylated MAPK (pMAPK) (Thr202/204) were observed in the nucleus and cytoplasm (Figure

1D). Overall, comparison of HNPC tumours and CRPC tumours revealed no differences in total or average expression levels of either Raf-1 (and all phosphorylated forms) (Table 1) or MAPK

(activated or inactivate, nuclear or cytoplasmic) (Table 2). However, analysis of matched pairs revealed a subgroup that showed significant increases in Raf-1 and MAPK levels in CRPC

tumours. We have previously reported that patients whose Raf-1 expression rose in this cohort with the development of CRPC had a significantly shorter time to relapse than those patients who

had a fall or no change (_P_=0.0005) (Mukherjee et al, 2005). Consistent with this observation, patients with rising levels of nuclear pRaf (Ser338, activated Raf-1) had a significantly

shorter time to biochemical relapse (2.2 years; range: 1.84–2.56 years) by 2.4 years when compared with patients who showed a fall in levels (4.6 years; range: 3.4–5.8 years) (_P_=0.01)

(Figure 2). Patients whose nuclear MAPK expression rose with the development of CRPC had a significantly shorter time to death from relapse (1.40 (1.20–1.61) years) compared with samples

that showed a fall or no change in expression (3.00 (1.43–4.57) years), _P_=0.0255 (Figure 3A). This translated into a shorter disease-specific survival of 3.37 (1.58–5.16 ) years compared

with 6.89 (5.70–8.08) years, _P_=0.0068 (Figure 3B). Interestingly, there was also an association seen between rising cytoplasmic pMAPK (Thr202/204) expression and reduced time to

biochemical relapse (_P_=0.06). RELATIVE PROTEIN EXPRESSION LEVELS IN HORMONE-NAÏVE PROSTATE CANCER In HNPC tumours, Raf-1 correlated with the inactive form, pRaf (Ser259), before relapse

(_P_=0.0041, _r_2=0.1201). Nuclear pRaf (Ser338) and cytoplasmic pRaf (Ser338) strongly correlated with each other (_P_=0.0035, _r_2=0.1381). No correlations between total Raf-1 and

cytoplasmic pRaf (Ser338) or nuclear pRaf (Ser338) expression were evident. In addition no correlations were observed between the inactive form of pRaf (Ser259) and nuclear pRaf (Ser338) or

cytoplasmic pRaf (Ser338). Total cytoplasmic expression of MAPK correlated with total nuclear expression of MAPK (_P_=0.0126, _r_2=0.1009), activated MAPK (Thr202/204) (_P_=0.0152,

_r_2=0.1044) and the cytoplasmic expression of MAPK (Thr202/204) (_P_<0.0001, _r_2=0.3391). Total nuclear MAPK expression correlated very strongly with the activated form of MAPK

(Thr202/204) in the nucleus (_P_<0.0001, _r_2=0.3447) and pMAPK (Thr202/204) in the cytoplasm (_P_=0.0075, _r_2=0.1250). Activated cytoplasmic MAPK (Thr202/204) also very strongly

associated with its activated expression (MAPK pThr202) in the nucleus (_P_<0.0001, _r_2=0.5210). In addition, Raf-1 and pRaf (Ser259) both correlated with the cytoplasmic expression of

MAPK (_P_<0.0001, _r_2=0.2979 and _P_=0.0005, _r_2=0.1879, respectively) and activated cytoplasmic MAPK (Thr202/204) (_P_=0.0007, _r_2=0.1826 and _P_=0.0069, _r_2=0.1214, respectively).

Raf-1 also correlated with nuclear activated MAPK (Thr202/204) (_P_=0.0022, _r_2=0.1525). There were no correlations seen between pRaf (Ser338) and MAPK or pMAPK (Thr202/204). RELATIVE

PROTEIN EXPRESSION LEVELS IN CRPC In CRPC tumours, Raf-1 correlated with pRaf (Ser259) strongly (_P_=0.0003, _r_2=0.1778). The nuclear and cytoplasmic forms of pRaf (Ser338) also strongly

correlated with each other (_P_<0.0001, _r_2=0.6009). Similarly to HNPC, protein expression of the inactive form of pRaf (Ser259) and the active forms of pRaf (Ser338) did not correlate

in the cell cytoplasm or nucleus. After the development of CRPC, cytoplasmic expression of total MAPK became strongly associated with the expression of total MAPK in the nucleus

(_P_=<0.0001, _r_2=0.2564) and more weakly with its activated form, pMAPK (Thr202/204), in the nucleus (_P_=0.0194, _r_2=0.0864). Cytoplasmic expression of total MAPK continued to show a

correlation with its activated form in the cytoplasm (MAPK pThr202/204) (_P_=0.0004, _r_2=0.1861). Activated cytoplasmic MAPK (Thr202/204) remained strongly associated with activated nuclear

MAPK (Thr202/204) (_P_<0.0001, _r_2=0.5350). Raf-1 showed similar associations with cytoplasmic and nuclear MAPK expression (_P_<0.0001, _r_2=0.2141 and _P_=0.0016, _r_2=0.1426,

respectively). Cytoplasmic MAPK also correlated with pRaf (Ser259) (_P_=0.0026, _r_2=0.1329). Similarly to HNPC tumours, no correlations were noted between pRaf (Ser338) and MAPK in any

location or form. RELATIVE EXPRESSION LEVELS OF RAF-1 AND MAPK COMPARED WITH UPSTREAM AND DOWNSTREAM TARGETS IN HORMONE-NAÏVE PROSTATE CANCER Analysis of the upstream activators EGFR and

Her2, as well as the downstream targets AR and AP-1, has previously been carried out on the same cohort of patients (Edwards et al, 2003a, 2004; Bartlett et al, 2005). We therefore

correlated Raf-1 and MAPK expression with these previous results, to determine the differences in the entire pathway in the transition from HNPC to CRPC. In hormone-naïve tumours, expression

of the putative growth factor receptor Her2 correlated with Raf-1 expression (_P_=0.0099, _r_2=0.1333) and the nuclear and cytoplasmic expression of pMAPK (Thr202/204) (_P_=0.0150,

_r_2=0.1300 and _P_=0.0017, _r_2=0.2074, respectively). Once activated, the phosphorylated form of Her2 (pHer2) showed moderate correlations with Raf-1 (_P_=0.0056, _r_2=0.1435), pRaf

(Ser259) (_P_=0.0052, _r_2=0.1459) and cytoplasmic MAPK expression (_P_=0.0123, _r_2=0.1211) (Figure 4), but not the activated forms of Raf or MAPK. No correlations were seen with EGFR in

HNPC tumours, except weak correlations with Raf-1 (_P_=0.0439, _r_2=0.06008) and pMAPK (Thr202/204) (nuclear) (_P_=0.0243, _r_2=0.0844). However, the mutant variant, EGFR vIII, did correlate

strongly with cytoplasmic expression of MAPK (_P_<0.0001, _r_2=0.2617) and to a weaker extent with Raf-1 (_P_=0.025, _r_2=0.07965) and pRaf (Ser259) (_P_=0.0323, _r_2=0.07295). Further

downstream, activated pRaf (Ser338) in the cytoplasm strongly correlated with phosphorylated c-jun (_P_=0.0009, _r_2=0.2673) and total MAPK (cytoplasmic) correlated weakly with c-Fos

(_P_=0.0453, _r_2=0.09418) (Figure 5). There were no correlations seen between MAPK and its activated form with c-jun, phospho c-Jun or c-Fos. In addition, PSA showed weak correlations with

Raf-1 (_P_=0.0142, _r_2=0.09604), pRaf (Ser259) (_P_=0.043, _r_2=0.06547), and showed links to overall MAPK levels, MAPK (nuclear) (_P_=0.0029, _r_2=0.1502) and MAPK (cytoplasmic)

(_P_<0.0001, _r_2=0.2467), with strong ties to the activated forms, pMAPK (Thr202/204) (cytoplasmic) (_P_<0.0001, _r_2=0.2891) and pMAPK (Thr202/204) (nuclear) (_P_=0.0001,

_r_2=0.2233) (Figure 6), whereas AR showed no correlations with Raf, MAPK or any of their forms. RELATIVE EXPRESSION LEVELS OF RAF-1 AND MAPK COMPARED WITH UPSTREAM AND DOWNSTREAM TARGETS IN

CRPC After the development of CRPC, Her2 no longer showed a correlation with Raf-1 nor a negative association became evident between pRaf (Ser338) both in the cytoplasm (_P_=0.0035,

_r_2=0.1854) and nucleus (_P_=0.0068, _r_2=0.1581) with Her2. In addition, the activated form (pHer2) correlated with pRaf (Ser259) (_P_=0.0008, _r_2=0.2011). Interestingly, the activated

cytoplasmic form of Raf showed a positive weak correlation with the pHer2 (_P_=0.0363, _r_2=0.09376) (Figure 7). Furthermore, no correlations were evident between Her2 or pHer2 with MAPK in

any form. All associations between EGFR and EGFR vIII disappeared after progression to CRPC. A moderate positive correlation was seen between pRaf (Ser259) and AR (_P_=0.0035, _r_2=0.1154),

whereas a negative correlation is evident between nuclear MAPK and AR (_P_=0.0429, _r_2=0.06066). There was no correlation (positive or negative) shown between total Raf-1 expression and AR.

In addition, there were no correlations noted between either Raf-1 (any form) or MAPK (any form) and PSA level. More correlations were noted with components of the downstream transcription

factor AP-1. Correlations were evident between phosphorylated c-jun and cytoplasmic pRaf (Ser338) (_P_=0.0026, _r_2=0.2192) and pRaf (Ser259) (_P_=0.0278, _r_2=0.1077). There was also a

correlation seen between Raf-1 and c-Fos (_P_=0.0131, _r_2=0.1512), and between the nuclear and cytoplasmic expression of pMAPK (Thr202/204) and c-jun (_P_=0.0146, _r_2=0.1368 and

_P_=0.0178, _r_2=0.1295, respectively) (Figure 8). DISCUSSION The MAPK pathway is known to have critical roles in the control of the cell cycle, growth and prevention of apoptosis (Bradham

and McClay, 2006). This pathway has been implicated in the development of CRPC and circumvention of AR involvement in prostate cancer (Edwards et al, 2003b). Raf is well known to be involved

in a broad range of cancers (Jilaveanu et al, 2009) and is considered to be an oncogene that drives the MAPK pathway and proliferation to enhance tumourigenesis (Karreth et al, 2009). The

upstream activator of Raf, Ras, has also previously been identified as being linked to tumourigenesis (Edwards and Bartlett, 2005). The distribution of Raf-1 (Roskoski, 2010) and MAPK

(Cuadrado and Nebreda, 2010) observed by immunohistochemistry is consistent with the current understanding of their cellular localisation and functions, indicating that their localisation

and functions were not disrupted during tumourigenesis, their levels however showed a very broad range of fluctuations. The data presented here suggests that Raf-1 activates MAPK in the

cytoplasm, which in turn translocates to the nucleus. No correlations were observed between activated Raf-1 and activated MAPK; however, this was not unexpected as Raf-1 becomes rapidly

inactivated and phosphorylated at serine 259 in the cytoplasm. Raf has been shown to have the ability to circumvent the MAPK pathway by acting directly upon retinoblastoma protein (Dhillon

et al, 2003; Dasgupta et al, 2004). The very strong correlations between cytoplasmic and nuclear activated Raf levels and the weaker correlations between Raf and MAPK may indicate that a

small portion of Raf activity may be attributable to MAPK-independent action. The lack of any clear links between active Raf and active MAPK in CRPC would appear to indicate that the two

pathways can and do operate independently in the latter stages of prostate cancer. In addition, the tight correlations present between the various forms of MAPK after transition to CRPC is a

strong indicator that this pathway has become very active in either the transition to or progression of CRPC. There are several correlations between PSA levels and both Raf and MAPK (all

forms) indicating a clear and distinct link between PSA and these pathways in HNPC. Interestingly, these correlations are completely absent in CRPC, giving further indication that these

pathways have become dislocated with the general indicators associated with prostate cancer (i.e., PSA and Gleason score). This may indicate a reason for PSA being useful in the initial

diagnosis of prostate cancer, but not in determining hormone relapse or overall survival (Supplementary Figure 1). Furthermore, this may indicate that markers in the Raf and MAPK pathways

may be more appropriate targets for monitoring disease progression. Interestingly, there are links between active MAPK (Thr202/204) and HER2 in HNPC, which are completely absent in CRPC; in

addition, there are no links between pRaf (Ser338) and Her2 or pHer2 in HNPC, which shifts to negative correlations between pRaf (Ser338) and Her2 in CRPC. Intriguingly, there is a complete

swing from activated cytoplasmic Raf (Ser338) from this negative correlation with Her2 to a positive correlation with pHer2. This may be an indicator that the Her2 signalling pathway has

become active and is signalling through Raf; this idea is enhanced by the correlation of cytoplasmic activated Raf (Ser338) with phospho c-Jun. Taken together, these data suggest that Her2

is signalling through Raf and ultimately through c-Jun (AP-1), as we have suggested previously (Edwards et al, 2004), to circumvent AR activity after the tumour has become insensitive to

androgens, as AP-1 has been shown to act independently of AR to activate some of the AR-associated genes (Sato et al, 1997). Furthermore, the links between activated MAPK and c-Jun, but a

lack of any links with Her2 or EGFR, is further evidence that MAPK and Raf are acting independently of each other to achieve the same end goal. Both MAPK and PKC have been shown to

phosphorylate c-Jun directly to stabilise it (Sato et al, 1997; Sadar et al, 1999; Bonaccorsi et al, 2003); however, the lack of correlation between MAPK and phospho c-Jun, in addition to

our previous findings that phopho c-Jun is upregulated in 61% of cases (Edwards et al, 2004), suggests that MAPK is not acting through this mechanism. In fact, the evidence indicates that

MAPK may have a role in c-Jun activation of AR, by promotion of dimerisation (Wise et al, 1998), in the absence of hormones. This provides a mechanism for the activation of

androgen-activated genes without the need for the androgen signal, thus making the tumour insensitive to hormone withdrawal. The links between Raf and the components of AP-1 are stronger

than with MAPK, which may further suggest that Raf is the important component in driving the stabilisation of AP-1. This evidence suggests that two pathways to circumvent the need for

hormones may be present and active in CRPC, and these allow tumours to continue to grow unabated without the need for hormones to drive proliferation and metastasis. Furthermore, it

indicates that members of the Raf and MAPK pathways would be potential targets for intervention therapy in the treatment of CRPC tumours. In addition, we have previously reported an increase

in AR levels in 65% of CRPC cases (Edwards et al, 2001), which alone was not overly significant; however, combined with stabilisation through c-Jun and phosphorylation from the MAPK

cascade, the small increase becomes highly significant with increased activity. This may also explain the correlation that exists between levels of MAPK in the nucleus and levels of AR found

in CRPC tumours. From the results presented here, it is evident that increasing levels of Raf-1 and/or MAPK are indicative of more rapid biochemical relapse and a more rapid decline into

CRPC, which ultimately results in reduced survival times, with tumours showing more severe and aggressive action. This suggests that these members of this pathway are vital components and

may be used as indicators of disease severity, providing a more accurate system for grading prostate cancer, in particular CRPC, than other systems in use, for example ,breast cancer (Galea

et al, 1992), which have proven insufficient in classifying prostate cancer. Furthermore, it suggests that these pathways are involved in the development of CRPC. Ultimately, the Raf and

MAPK pathways may turn out to be excellent targets for preventative therapy, as well as providing potential prognostic and/or diagnostic markers. CHANGE HISTORY * _ 29 MARCH 2012 This paper

was modified 12 months after initial publication to switch to Creative Commons licence terms, as noted at publication _ REFERENCES * Abreu-Martin MT, Chari A, Palladino AA, Craft NA, Sawyers

CL (1999) Mitogen-activated protein kinase kinase kinase 1 activates androgen receptor-dependent transcription and apoptosis in prostate cancer. _Mol Cell Biol_ 19: 5143–5154 Article  CAS

PubMed  PubMed Central  Google Scholar  * Alessandrini A, Chiaur DS, Pagano M (1997) Regulation of the cyclin-dependent kinase inhibitor p27 by degradation and phosphorylation. _Leukemia_

11: 342–345 Article  CAS  PubMed  Google Scholar  * Bakin RE, Gioeli D, Sikes RA, Bissonette EA, Weber MJ (2003) Constitutive activation of the Ras/mitogen-activated protein kinase signaling

pathway promotes androgen hypersensitivity in LNCaP prostate cancer cells. _Cancer Res_ 63: 1981–1989 CAS  PubMed  Google Scholar  * Bartlett JM, Brawley D, Grigor K, Munro AF, Dunne B,

Edwards J (2005) Type I receptor tyrosine kinases are associated with hormone escape in prostate cancer. _J Pathol_ 205: 522–529 Article  CAS  PubMed  Google Scholar  * Beemsterboer PM, de

Koning HJ, Birnie E, van der Maas PJ, Schroder FH (1999) Advanced prostate cancer: course, care, and cost implications. _Prostate_ 40: 97–104 Article  CAS  PubMed  Google Scholar  *

Bonaccorsi L, Muratori M, Carloni V, Zecchi S, Formigli L, Forti G, Baldi E (2003) Androgen receptor and prostate cancer invasion. _Int J Androl_ 26: 21–25 Article  CAS  PubMed  Google

Scholar  * Bradham C, McClay DR (2006) p38 MAPK in development and cancer. _Cell Cycle_ 5: 824–828 Article  CAS  PubMed  Google Scholar  * CancerResearchUK (2010)

http://info.cancerresearchuk.org/cancerstats/incidence/ * Cuadrado A, Nebreda AR (2010) Mechanisms and functions of p38 MAPK signalling. _Biochem J_ 429: 403–417 Article  CAS  PubMed  Google

Scholar  * Culig Z, Klocker H, Bartsch G, Hobisch A (2002) Androgen receptors in prostate cancer. _Endocr Relat Cancer_ 9: 155–170 Article  CAS  PubMed  Google Scholar  * Dasgupta P, Sun J,

Wang S, Fusaro G, Betts V, Padmanabhan J, Sebti SM, Chellappan SP (2004) Disruption of the Rb–Raf-1 interaction inhibits tumor growth and angiogenesis. _Mol Cell Biol_ 24: 9527–9541 Article

  CAS  PubMed  PubMed Central  Google Scholar  * Debes JD, Tindall DJ (2004) Mechanisms of androgen-refractory prostate cancer. _N Engl J Med_ 351: 1488–1490 Article  CAS  PubMed  Google

Scholar  * Dhillon AS, Meikle S, Peyssonnaux C, Grindlay J, Kaiser C, Steen H, Shaw PE, Mischak H, Eychene A, Kolch W (2003) A Raf-1 mutant that dissociates MEK/extracellular

signal-regulated kinase activation from malignant transformation and differentiation but not proliferation. _Mol Cell Biol_ 23: 1983–1993 Article  CAS  PubMed  PubMed Central  Google Scholar

  * Dorkin TJ, Neal DE (1997) Basic science aspects of prostate cancer. _Semin Cancer Biol_ 8: 21–27 Article  CAS  PubMed  Google Scholar  * Edwards J, Bartlett JM (2005) The androgen

receptor and signal-transduction pathways in hormone-refractory prostate cancer. Part 1: modifications to the androgen receptor. _BJU Int_ 95: 1320–1326 Article  CAS  PubMed  Google Scholar

  * Edwards J, Krishna NS, Grigor KM, Bartlett JM (2003a) Androgen receptor gene amplification and protein expression in hormone refractory prostate cancer. _Br J Cancer_ 89: 552–556 Article

  CAS  PubMed  PubMed Central  Google Scholar  * Edwards J, Krishna NS, Mukherjee R, Bartlett JM (2004) The role of c-Jun and c-Fos expression in androgen-independent prostate cancer. _J

Pathol_ 204: 153–158 Article  CAS  PubMed  Google Scholar  * Edwards J, Krishna NS, Mukherjee R, Watters AD, Underwood MA, Bartlett JM (2001) Amplification of the androgen receptor may not

explain the development of androgen-independent prostate cancer. _BJU Int_ 88: 633–637 Article  CAS  PubMed  Google Scholar  * Edwards J, Krishna NS, Witton CJ, Bartlett JM (2003b) Gene

amplifications associated with the development of hormone-resistant prostate cancer. _Clin Cancer Res_ 9: 5271–5281 CAS  PubMed  Google Scholar  * Edwards J, Traynor P, Munro AF, Pirret CF,

Dunne B, Bartlett JM (2006) The role of HER1-HER4 and EGFRvIII in hormone-refractory prostate cancer. _Clin Cancer Res_ 12: 123–130 Article  CAS  PubMed  Google Scholar  * Franco OE, Onishi

T, Yamakawa K, Arima K, Yanagawa M, Sugimura Y, Kawamura J (2003) Mitogen-activated protein kinase pathway is involved in androgen-independent PSA gene expression in LNCaP cells. _Prostate_

56: 319–325 Article  CAS  PubMed  Google Scholar  * Fu Z, Smith PC, Zhang L, Rubin MA, Dunn RL, Yao Z, Keller ET (2003) Effects of raf kinase inhibitor protein expression on suppression of

prostate cancer metastasis. _J Natl Cancer Inst_ 95: 878–889 Article  CAS  PubMed  Google Scholar  * Galea MH, Blamey RW, Elston CE, Ellis IO (1992) The Nottingham Prognostic Index in

primary breast cancer. _Breast Cancer Res Treat_ 22: 207–219 Article  CAS  PubMed  Google Scholar  * Gao X, Porter AT, Grignon DJ, Pontes JE, Honn KV (1997) Diagnostic and prognostic markers

for human prostate cancer. _Prostate_ 31: 264–281 Article  CAS  PubMed  Google Scholar  * Gioeli D, Mandell JW, Petroni GR, Frierson Jr HF, Weber MJ (1999) Activation of mitogen-activated

protein kinase associated with prostate cancer progression. _Cancer Res_ 59: 279–284 CAS  PubMed  Google Scholar  * Huggins C, Hodges CV (2002) Studies on prostatic cancer: I. The effect of

castration, of estrogen and of androgen injection on serum phosphatases in metastatic carcinoma of the prostate. 1941. _J Urol_ 168: 9–12 Article  PubMed  Google Scholar  * Jilaveanu LB,

Zito CR, Aziz SA, Conrad PJ, Schmitz JC, Sznol M, Camp RL, Rimm DL, Kluger HM (2009) C-Raf is associated with disease progression and cell proliferation in a subset of melanomas. _Clin

Cancer Res_ 15: 5704–5713 Article  CAS  PubMed  PubMed Central  Google Scholar  * Karreth FA, DeNicola GM, Winter SP, Tuveson DA (2009) C-Raf inhibits MAPK activation and transformation by

B-Raf(V600E). _Mol Cell_ 36: 477–486 Article  CAS  PubMed  Google Scholar  * Khleif SN, Abrams SI, Hamilton JM, Bergmann-Leitner E, Chen A, Bastian A, Bernstein S, Chung Y, Allegra CJ,

Schlom J (1999) A phase I vaccine trial with peptides reflecting ras oncogene mutations of solid tumors. _J Immunother_ 22: 155–165 Article  CAS  PubMed  Google Scholar  * Linja MJ,

Savinainen KJ, Saramaki OR, Tammela TL, Vessella RL, Visakorpi T (2001) Amplification and overexpression of androgen receptor gene in hormone-refractory prostate cancer. _Cancer Res_ 61:

3550–3555 CAS  PubMed  Google Scholar  * Mukherjee R, Bartlett JM, Krishna NS, Underwood MA, Edwards J (2005) Raf-1 expression may influence progression to androgen insensitive prostate

cancer. _Prostate_ 64: 101–107 Article  CAS  PubMed  Google Scholar  * Roskoski Jr R (2010) RAF protein-serine/threonine kinases: structure and regulation. _Biochem Biophys Res Commun_ 399:

313–317 Article  CAS  PubMed  Google Scholar  * Sadar MD, Hussain M, Bruchovsky N (1999) Prostate cancer: molecular biology of early progression to androgen independence. _Endocr Relat

Cancer_ 6: 487–502 Article  CAS  PubMed  Google Scholar  * Sato N, Sadar MD, Bruchovsky N, Saatcioglu F, Rennie PS, Sato S, Lange PH, Gleave ME (1997) Androgenic induction of

prostate-specific antigen gene is repressed by protein–protein interaction between the androgen receptor and AP-1/c-Jun in the human prostate cancer cell line LNCaP. _J Biol Chem_ 272:

17485–17494 Article  CAS  PubMed  Google Scholar  * Sciarra A, Casale P, Colella D, Di Chiro C, Di Silverio F (1999) Hormone-refractory prostate cancer? Anti-androgen withdrawal and

intermittent hormone therapy. _Scand J Urol Nephrol_ 33: 211–216 Article  CAS  PubMed  Google Scholar  * Stamey TA, Yang N, Hay AR, McNeal JE, Freiha FS, Redwine E (1987) Prostate-specific

antigen as a serum marker for adenocarcinoma of the prostate. _N Engl J Med_ 317: 909–916 Article  CAS  PubMed  Google Scholar  * Ueda T, Bruchovsky N, Sadar MD (2002) Activation of the

androgen receptor N-terminal domain by interleukin-6 via MAPK and STAT3 signal transduction pathways. _J Biol Chem_ 277: 7076–7085 Article  CAS  PubMed  Google Scholar  *

Weinstein-Oppenheimer CR, Blalock WL, Steelman LS, Chang F, McCubrey JA (2000) The Raf signal transduction cascade as a target for chemotherapeutic intervention in growth factor-responsive

tumors. _Pharmacol Ther_ 88: 229–279 Article  CAS  PubMed  Google Scholar  * Wirth MP, See WA, McLeod DG, Iversen P, Morris T, Carroll K (2004) Bicalutamide 150 mg in addition to standard

care in patients with localized or locally advanced prostate cancer: results from the second analysis of the early prostate cancer program at median followup of 5.4 years. _J Urol_ 172:

1865–1870 Article  CAS  PubMed  Google Scholar  * Wise SC, Burmeister LA, Zhou XF, Bubulya A, Oberfield JL, Birrer MJ, Shemshedini L (1998) Identification of domains of c-Jun mediating

androgen receptor transactivation. _Oncogene_ 16: 2001–2009 Article  CAS  PubMed  Google Scholar  * Yeh S, Lin HK, Kang HY, Thin TH, Lin MF, Chang C (1999) From HER2/Neu signal cascade to

androgen receptor and its coactivators: a novel pathway by induction of androgen target genes through MAP kinase in prostate cancer cells. _Proc Natl Acad Sci USA_ 96: 5458–5463 Article  CAS

  PubMed  PubMed Central  Google Scholar  * Zelivianski S, Spellman M, Kellerman M, Kakitelashvilli V, Zhou XW, Lugo E, Lee MS, Taylor R, Davis TL, Hauke R, Lin MF (2003) ERK inhibitor

PD98059 enhances docetaxel-induced apoptosis of androgen-independent human prostate cancer cells. _Int J Cancer_ 107: 478–485 Article  CAS  PubMed  Google Scholar  Download references

ACKNOWLEDGEMENTS We thank Dr Tove Kirkegaard and Liane McGlynn for all their help and assistance in the completion of this work. This work was supported by grants from Prostate Research

Campaign UK, Glasgow Royal Infirmary Research Endowment Fund, Think Pink and AICR. AUTHOR INFORMATION AUTHORS AND AFFILIATIONS * College of Medical, Veterinary and Life Sciences, Institute

of Cancer, McGregor Building, Glasgow Western Infirmary, Glasgow, G11 6NT, UK R Mukherjee, D H McGuinness, P McCall & J Edwards * Department of Urology, Glasgow Royal Infirmary, Glasgow,

G31 2ER, UK R Mukherjee & M A Underwood * Department of Pathology, McGregor Building, Western Infirmary, Glasgow, G11 6NT, UK M Seywright & C Orange Authors * R Mukherjee View

author publications You can also search for this author inPubMed Google Scholar * D H McGuinness View author publications You can also search for this author inPubMed Google Scholar * P

McCall View author publications You can also search for this author inPubMed Google Scholar * M A Underwood View author publications You can also search for this author inPubMed Google

Scholar * M Seywright View author publications You can also search for this author inPubMed Google Scholar * C Orange View author publications You can also search for this author inPubMed

Google Scholar * J Edwards View author publications You can also search for this author inPubMed Google Scholar CORRESPONDING AUTHOR Correspondence to J Edwards. ETHICS DECLARATIONS

COMPETING INTERESTS No part of this paper has been submitted for publication or published elsewhere. There are no conflicts of interest or financial relationships with regard to this

publication. All authors have met the requirements for authorship and have read and approved the manuscript in this form. ADDITIONAL INFORMATION Supplementary Information accompanies the

paper on British Journal of Cancer website SUPPLEMENTARY INFORMATION SUPPLEMENTARY FIGURE 1 (DOC 285 KB) RIGHTS AND PERMISSIONS From twelve months after its original publication, this work

is licensed under the Creative Commons Attribution-NonCommercial-Share Alike 3.0 Unported License. To view a copy of this license, visit http://creativecommons.org/licenses/by-nc-sa/3.0/

Reprints and permissions ABOUT THIS ARTICLE CITE THIS ARTICLE Mukherjee, R., McGuinness, D., McCall, P. _et al._ Upregulation of MAPK pathway is associated with survival in

castrate-resistant prostate cancer. _Br J Cancer_ 104, 1920–1928 (2011). https://doi.org/10.1038/bjc.2011.163 Download citation * Received: 07 February 2011 * Revised: 12 April 2011 *

Accepted: 17 April 2011 * Published: 10 May 2011 * Issue Date: 07 June 2011 * DOI: https://doi.org/10.1038/bjc.2011.163 SHARE THIS ARTICLE Anyone you share the following link with will be

able to read this content: Get shareable link Sorry, a shareable link is not currently available for this article. Copy to clipboard Provided by the Springer Nature SharedIt content-sharing

initiative KEYWORDS * MAP kinase pathway * castrate-resistant prostate cancer * prostate cancer * Her2 * AP-1 * Raf
